Description: Voltage: 24V
Warranty: 12 months
Product code: INVSOL03
Size: 272 x 355 x 100 mm
Weight: 8.5kg
Output Voltage: 230V AC
Output frequency: 50Hz or 60Hz (auto detection)
Shape of the output voltage: Pure Sinusoid
Efficiency: 98%
Usable power (continuous): 2000W
Instantaneous power (impulsive): 4000W
Pobór mocy (bez obciążenia): 2W
Battery voltage: 24V
Maximum PV voltage (VOC): 145VDC
Inverter efficiency: 90%-93%
AC voltage adjustment (battery mode): 220VAC - 240VAC (can be determined)
Charging voltage: 27.4V
PV voltage range for MPPT: 30-120VDC
Maximum PV power: 1500W
Maximum MPPT output current: 60A

Compatibility list:

Compatible with following battery models :

Compatible with following devices :
